Overlay Toolbar in .NET MAUI Toolbar (SfToolbar)

2 Mar 202624 minutes to read

The toolbar control supports displaying an overlay toolbar in the view. You can add the SfOverlayToolbar to the OverlayToolbar property of SfToolbarItem. The SfOverlayToolbar includes a built-in back button, which can be used to close the overlay toolbar.

How to display the overlay toolbar

To display an overlay toolbar, define the OverlayToolbar property for a toolbar item. When the toolbar item is tapped, the overlay toolbar will appear. The following example shows how to add an overlay toolbar to a toolbar item.

NOTE

There is no need to set framework‑specific layout properties such as Height, Width, FlowDirection, or explicit frame bounds for the overlay toolbar. The overlay toolbar automatically aligns with the main toolbar, inheriting its layout, size, and orientation. All sizing and flow behavior are managed by the main toolbar.

<?xml version="1.0" encoding="utf-8" ?>
<ContentPage xmlns="http://schemas.microsoft.com/dotnet/2021/maui"
             xmlns:x="http://schemas.microsoft.com/winfx/2009/xaml"
             xmlns:local="clr-namespace:ToolbarSample"
             xmlns:toolbar="clr-namespace:Syncfusion.Maui.Toolbar;assembly=Syncfusion.Maui.Toolbar"
             x:Class="ToolbarSample.MainPage">
    <Grid x:Name="layout">
        <toolbar:SfToolbar x:Name="Toolbar"
                                HeightRequest="56"
                                WidthRequest="300">
            <toolbar:SfToolbar.Items>
                <toolbar:SfToolbarItem Name="Bold"
                            ToolTipText="Bold">
                    <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE770;"
                                            FontFamily="MauiMaterialAssets" />
                    </toolbar:SfToolbarItem.Icon>
                </toolbar:SfToolbarItem>
                <toolbar:SfToolbarItem Name="Underline"
                            ToolTipText="Underline">
                    <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE762;"
                                            FontFamily="MauiMaterialAssets" />
                    </toolbar:SfToolbarItem.Icon>
                </toolbar:SfToolbarItem>
                <toolbar:SfToolbarItem Name="Italic"
                            ToolTipText="Italic">
                    <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE771;"
                                            FontFamily="MauiMaterialAssets" />
                    </toolbar:SfToolbarItem.Icon>
                </toolbar:SfToolbarItem>
                <toolbar:SfToolbarItem Name="Alignment"
                                    Text="Alignment"
                                    ToolTipText="Tap to view the overlay toolbar"
                                    Size="70,40">
                <toolbar:SfToolbarItem.OverlayToolbar>
                    <toolbar:SfOverlayToolbar x:Name="overlaytoolbar">
                        <toolbar:SfOverlayToolbar.Items>
                            <toolbar:SfToolbarItem Name="AlignLeft"
                                                ToolTipText="Align-Left">
                                <toolbar:SfToolbarItem.Icon>
                                <FontImageSource Glyph="&#xE751;"
                                                        FontFamily="MauiMaterialAssets" />
                                </toolbar:SfToolbarItem.Icon>
                            </toolbar:SfToolbarItem>
                            <toolbar:SfToolbarItem Name="AlignRight"
                                                ToolTipText="Align-Right">
                                <toolbar:SfToolbarItem.Icon>
                                <FontImageSource Glyph="&#xE753;"
                                            FontFamily="MauiMaterialAssets" />
                                </toolbar:SfToolbarItem.Icon>
                            </toolbar:SfToolbarItem>
                            <toolbar:SfToolbarItem Name="AlignCenter"
                                                ToolTipText="Align-Center">
                                <toolbar:SfToolbarItem.Icon>
                                <FontImageSource Glyph="&#xE752;"
                                            FontFamily="MauiMaterialAssets" />
                                </toolbar:SfToolbarItem.Icon>
                            </toolbar:SfToolbarItem>
                            <toolbar:SfToolbarItem Name="AlignJustify"
                                                ToolTipText="Align-Justify">
                                <toolbar:SfToolbarItem.Icon>
                                <FontImageSource Glyph="&#xE74F;"
                                            FontFamily="MauiMaterialAssets" />
                                </toolbar:SfToolbarItem.Icon>
                            </toolbar:SfToolbarItem>
                        </toolbar:SfOverlayToolbar.Items>
                    </toolbar:SfOverlayToolbar>
                </toolbar:SfToolbarItem.OverlayToolbar>
                </toolbar:SfToolbarItem>
            </toolbar:SfToolbar.Items>
        </toolbar:SfToolbar>
    </Grid>
</ContentPage>
using Syncfusion.Maui.Toolbar;

namespace ToolbarSample
{
    public partial class MainPage : ContentPage
    {
        public MainPage()
        {
            InitializeComponent();
        }
    }
}

overlay-toolbar

Back icon customization

The toolbar control support customization of back icon using properties BackIconAlignment, BackIconColor, BackIconToolTipText, BackIconTemplate.

  • BackIconColor – This property is used to define the color of the back icon displayed in the overlay toolbar.
  • BackIconAlignment – This property defines the position of the back icon within the overlay toolbar. It supports two position options: Start, which places the icon at the leading edge, and End, which positions it at the trailing edge. By default, the back icon appears at the leading position.

NOTE

For a Horizontal orientation, the Start position corresponds to the left side and the End position to the right. In a Vertical orientation, the Start position aligns with the top, while the End position aligns with the bottom.

  • BackIconTemplate – This property allows customization of the back icon’s appearance by enabling the use of various view elements such as buttons, checkboxes, entries, and more.
  • BackIconToolTipText – This property is used to define the tooltip text displayed when hovering over the back icon.

NOTE

TooltipText is only applicable to the default back icon. When using BackIconTemplate, tooltip behavior must be handled manually.

<Grid x:Name="layout">
    <toolbar:SfToolbar x:Name="Toolbar"
                            HeightRequest="56"
                            WidthRequest="300">
        <toolbar:SfToolbar.Items>
            <toolbar:SfToolbarItem Name="Bold"
                        ToolTipText="Bold">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE770;"
                                        FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Underline"
                        ToolTipText="Underline">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE762;"
                                        FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Italic"
                        ToolTipText="Italic">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE771;"
                                        FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Alignment"
                                Text="Alignment"
                                ToolTipText="Tap to view the overlay toolbar"
                                Size="70,40">
                <toolbar:SfToolbarItem.OverlayToolbar>
                    <toolbar:SfOverlayToolbar x:Name="overlaytoolbar"
                                              BackIconAlignment="End"
                                              BackIconToolTipText="Back"
                                              BackIconColor="Red">
                        <toolbar:SfOverlayToolbar.BackIconTemplate>
                            <DataTemplate>
                                <ViewCell>
                                    <Grid WidthRequest="47" HeightRequest="33" HorizontalOptions="Start">
                                        <ImageButton Source="close.png" InputTransparent="True" />
                                    </Grid>
                                </ViewCell>
                            </DataTemplate>
                        </toolbar:SfOverlayToolbar.BackIconTemplate>
                        <toolbar:SfOverlayToolbar.Items>
                            <toolbar:SfToolbarItem Name="AlignLeft"
                                            ToolTipText="Align-Left">
                                <toolbar:SfToolbarItem.Icon>
                                    <FontImageSource Glyph="&#xE751;"
                                                    FontFamily="MauiMaterialAssets" />
                                </toolbar:SfToolbarItem.Icon>
                            </toolbar:SfToolbarItem>
                            <toolbar:SfToolbarItem Name="AlignRight"
                                            ToolTipText="Align-Right">
                                <toolbar:SfToolbarItem.Icon>
                                    <FontImageSource Glyph="&#xE753;"
                                        FontFamily="MauiMaterialAssets" />
                                </toolbar:SfToolbarItem.Icon>
                            </toolbar:SfToolbarItem>
                            <toolbar:SfToolbarItem Name="AlignCenter"
                                            ToolTipText="Align-Center">
                                <toolbar:SfToolbarItem.Icon>
                                    <FontImageSource Glyph="&#xE752;"
                                        FontFamily="MauiMaterialAssets" />
                                </toolbar:SfToolbarItem.Icon>
                            </toolbar:SfToolbarItem>
                            <toolbar:SfToolbarItem Name="AlignJustify"
                                            ToolTipText="Align-Justify">
                                <toolbar:SfToolbarItem.Icon>
                                    <FontImageSource Glyph="&#xE74F;"
                                        FontFamily="MauiMaterialAssets" />
                                </toolbar:SfToolbarItem.Icon>
                            </toolbar:SfToolbarItem>

                        <toolbar:SeparatorToolbarItem/>

                        </toolbar:SfOverlayToolbar.Items>
                    </toolbar:SfOverlayToolbar>
                </toolbar:SfToolbarItem.OverlayToolbar>
            </toolbar:SfToolbarItem>
        </toolbar:SfToolbar.Items>
    </toolbar:SfToolbar>
</Grid>
namespace ToolbarSample
{
    public partial class MainPage : ContentPage
    {
        public MainPage()
        {
            InitializeComponent();
            var backIconTemplate = new DataTemplate(() =>
            {
            var grid = new Grid
            {
                WidthRequest = 47,
                HeightRequest = 33,
                HorizontalOptions = LayoutOptions.Start
            };
            var image = new ImageButton
            {
                Source = "close.png",
            };

            grid.Children.Add(image);

            var viewCell = new ViewCell
            {
                View = grid
            };

                return viewCell;
            });

            overlaytoolbar.BackIconTemplate = backIconTemplate;
            overlaytoolbar.BackIconColor = Colors.Blue;
            overlaytoolbar.BackIconToolTipText = "Back";
            overlaytoolbar.BackIconAlignment = OverlayToolbarBackIconPosition.End;
        }
    }
}

backicon-customization
