Customization in .NET MAUI Toolbar (SfToolbar)

This section explains the ways about support for customization in syncfusion .NET MAUI Toolbar (SfToolbar) control.

Toolbar Item Customization

The toolbar control supports customization of toolbar items using properties IsEnabled,TextStyle and Color.

  • IsEnabled : This property is used to enable or disable the toolbar item.
  • TextStyle : This property is used to customize the text style of the toolbar item.
  • Color : This property is used to set color for the icon in the toolbar.

The following code sample demonstrates how to create a toolbar control with toolbar Items customization.

<VerticalStackLayout  VerticalOptions="Center">
    <toolbar:SfToolbar x:Name="Toolbar" HeightRequest="56" WidthRequest="850">
        <toolbar:SfToolbar.Items>
            <toolbar:SfToolbarItem Name="Bold"
                        Text="Bold"
                        TextPosition="Right"
                        ToolTipText="Bold"
                        Size="60,56">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE770;"
 FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
                <toolbar:SfToolbarItem.TextStyle>
                    <toolbar:ToolbarTextStyle TextColor="Red"
                  FontSize="14"
                  FontAttributes="Bold"
                  FontFamily="OpenSansSemibold"
                  FontAutoScalingEnabled="True"/>
                </toolbar:SfToolbarItem.TextStyle>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Italic"
                       Text="Italic"
                       TextPosition="Right"
                       ToolTipText="Italic"
                       Size="60,56">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE771;"
 FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
                <toolbar:SfToolbarItem.TextStyle>
                    <toolbar:ToolbarTextStyle TextColor="Green"
                  FontSize="16"
                  FontAttributes="Italic"
                  FontFamily="OpenSansRegular"
                  FontAutoScalingEnabled="False"/>
                </toolbar:SfToolbarItem.TextStyle>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Text="Underline"
        TextPosition="Right" Size="100,56" IsEnabled="False"
                ToolTipText="Underline">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE762;"
            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Text="AlignLeft" TextPosition="Right" Size="100,56" IsEnabled="False"
                        ToolTipText="Align-Left">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE751;"
            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Text="AlignRight" TextPosition="Right" Size="100,56"
                        ToolTipText="Align-Right">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE753;" Color="Black"
            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Text="AlignCenter" TextPosition="Right" Size="120,56"
                        ToolTipText="Align-Center">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE752;" Color="Blue"
            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Text="AlignJustify" TextPosition="Right" Size="110,56"
                        ToolTipText="Align-Justify">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Color="Red" Glyph="&#xE74F;"
            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
        </toolbar:SfToolbar.Items>
    </toolbar:SfToolbar>
</VerticalStackLayout>
public partial class MainPage : ContentPage
 {
     public MainPage()
     {
         InitializeComponent();
         SfToolbar toolbar = new SfToolbar();
         toolbar.HeightRequest = 56;
         ObservableCollection<BaseToolbarItem> itemCollection = new ObservableCollection<BaseToolbarItem>
         {
             new SfToolbarItem
             {
                 Name = "Bold",
                 Text = "Bold",
                 TextPosition = ToolbarItemTextPosition.Right,
                 ToolTipText = "Bold",
                 Size = new Size(60, 56),
                 Icon = new FontImageSource { Glyph = "\uE770", FontFamily = "MauiMaterialAssets" },
                 TextStyle = new ToolbarTextStyle
                 {
                     TextColor = Colors.Red,
                     FontSize = 14,
                     FontAttributes = FontAttributes.Bold,
                     FontFamily = "OpenSansSemibold",
                     FontAutoScalingEnabled = true
                 }
             },
             new SfToolbarItem
             {
                 Name = "Italic",
                 Text = "Italic",
                 TextPosition = ToolbarItemTextPosition.Right,
                 ToolTipText = "Italic",
                 Size = new Size(60, 56),
                 Icon = new FontImageSource { Glyph = "\uE771", FontFamily = "MauiMaterialAssets" },
                 TextStyle = new ToolbarTextStyle
                 {
                     TextColor = Colors.Green,
                     FontSize = 16,
                     FontAttributes = FontAttributes.Italic,
                     FontFamily = "OpenSansRegular",
                     FontAutoScalingEnabled = false
                 }
             },
             new SfToolbarItem
             {
                 Text = "Underline",
                 TextPosition = ToolbarItemTextPosition.Right,
                 ToolTipText = "Underline",
                 Size = new Size(100, 56),
                 Icon = new FontImageSource { Glyph = "\uE762", FontFamily = "MauiMaterialAssets" },
             },
             new SfToolbarItem
             {
                 Text = "Italic",
                 TextPosition = ToolbarItemTextPosition.Right,
                 ToolTipText = "Italic",
                 Size = new Size(60, 56),
                 Icon = new FontImageSource { Glyph = "\uE771", FontFamily = "MauiMaterialAssets" },
             },
             new SfToolbarItem
             {
                 Text = "AlignLeft",
                 TextPosition = ToolbarItemTextPosition.Right,
                 ToolTipText = "Align-Left",
                 Size = new Size(100, 56),
                 Icon = new FontImageSource { Glyph = "\uE751", FontFamily = "MauiMaterialAssets" },
             },
             new SfToolbarItem
             {
                 Text = "AlignRight",
                 TextPosition = ToolbarItemTextPosition.Right,
                 ToolTipText = "Align-Right",
                 Size = new Size(100, 56),
                 Icon = new FontImageSource { Color="Black", Glyph = "\uE753", FontFamily = "MauiMaterialAssets" },
             },
             new SfToolbarItem
             {
                 Text = "AlignCenter",
                 TextPosition = ToolbarItemTextPosition.Right,
                 ToolTipText = "Align-Center",
                 Size = new Size(120, 56),
                 Icon = new FontImageSource { Color="Blue", Glyph = "\uE752", FontFamily = "MauiMaterialAssets" },
             },
             new SfToolbarItem
             {
                 Text = "AlignJustify",
                 TextPosition = ToolbarItemTextPosition.Right,
                 ToolTipText = "Align-Justify",
                 Size = new Size(110, 56),
                 Icon = new FontImageSource { Color="Red", Glyph = "\uE74F", FontFamily = "MauiMaterialAssets" },
             }
         };

         toolbar.Items = itemCollection;
         this.Content = toolbar;
     }
 }

toolbar-items-customization

Separator Item Customization

The toolbar control supports customization of separator item using properties Stroke and StrokeThickness.

  • Stroke : This property is used to customize the stroke color of the separator item.
  • StrokeThickness : This property is used to customize the stroke thickness of the separator item.

The following code sample demonstrates how to create a toolbar control with separator item customization.

<VerticalStackLayout>
    <toolbar:SfToolbar x:Name="Toolbar" HeightRequest="56" WidthRequest="450">
        <toolbar:SfToolbar.Items>
            <toolbar:SfToolbarItem Name="Bold"
            ToolTipText="Bold">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE770;"
                         FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Underline"
            ToolTipText="Underline">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE762;"
                         FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Italic"
            ToolTipText="Italic">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE771;"
                         FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SeparatorToolbarItem Stroke="Red" StrokeThickness="3"/>
            <toolbar:SfToolbarItem Name="AlignLeft"
                       ToolTipText="Align-Left">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE751;"
                         FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignRight"
                       ToolTipText="Align-Right">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE753;"
             FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignCenter"
                       ToolTipText="Align-Center">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE752;"
             FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignJustify"
                       ToolTipText="Align-Justify">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE74F;"
             FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
        </toolbar:SfToolbar.Items>
    </toolbar:SfToolbar>
</VerticalStackLayout>
public partial class MainPage : ContentPage
{
    public MainPage()
    {
        InitializeComponent();
        SfToolbar toolbar = new SfToolbar();
        toolbar.HeightRequest = 56;

        ObservableCollection<BaseToolbarItem> itemCollection = new ObservableCollection<BaseToolbarItem>
        {
            new SfToolbarItem
            {
                Name = "Bold",
                ToolTipText = "Bold",
                Icon = new FontImageSource { Glyph = "\uE770", FontFamily = "MauiMaterialAssets" }
            },
            new SfToolbarItem
            {
                Name = "Underline",
                ToolTipText = "Underline",
                Icon = new FontImageSource { Glyph = "\uE762", FontFamily = "MauiMaterialAssets" }
            },
            new SfToolbarItem
            {
                Name = "Italic",
                ToolTipText = "Italic",
                Icon = new FontImageSource { Glyph = "\uE771", FontFamily = "MauiMaterialAssets" }
            },
            new SeparatorToolbarItem
            {
                Stroke = Colors.Red,
                StrokeThickness = 3
            },
            new SfToolbarItem
            {
                Name = "AlignLeft",
                ToolTipText = "Align-Left",
                Icon = new FontImageSource { Glyph = "\uE751", FontFamily = "MauiMaterialAssets" }
            },
            new SfToolbarItem
            {
                Name = "AlignRight",
                ToolTipText = "Align-Right",
                Icon = new FontImageSource { Glyph = "\uE753", FontFamily = "MauiMaterialAssets" }
            },
            new SfToolbarItem
            {
                Name = "AlignCenter",
                ToolTipText = "Align-Center",
                Icon = new FontImageSource { Glyph = "\uE752", FontFamily = "MauiMaterialAssets" }
            },
            new SfToolbarItem
            {
                Name = "AlignJustify",
                ToolTipText = "Align-Justify",
                Icon = new FontImageSource { Glyph = "\uE74F", FontFamily = "MauiMaterialAssets" }
            }
        };

        toolbar.Items = itemCollection;
        this.Content = toolbar;
    }
}

separator-item-customization

The toolbar control supports customization of navigation buttons using properties ForwardButtonIconColor, BackwardButtonIconColor, ForwardButtonBackground, BackwardButtonBackground.

  • ForwardButtonIconColor : This property is used to customize the icon color of the forward button.
  • BackwardButtonIconColor : This property is used to customize the icon color of the backward button.
  • ForwardButtonBackground : This property is used to customize the background color of the forward button.
  • BackwardButtonBackground : This property is used to customize the background color of the backward button.

The following code sample demonstrates how to create a toolbar control with navigation button customization.

<VerticalStackLayout>
     <toolbar:SfToolbar x:Name="Toolbar" HeightRequest="56" WidthRequest="270" OverflowMode="NavigationButtons" ForwardButtonIconColor="Red" BackwardButtonIconColor="Red" ForwardButtonBackground="Aqua" BackwardButtonBackground="Aqua">
         <toolbar:SfToolbar.Items>
             <toolbar:SfToolbarItem Name="Bold"
             ToolTipText="Bold">
                 <toolbar:SfToolbarItem.Icon>
                     <FontImageSource Glyph="&#xE770;"
                          FontFamily="MauiMaterialAssets" />
                 </toolbar:SfToolbarItem.Icon>
             </toolbar:SfToolbarItem>
             <toolbar:SfToolbarItem Name="Underline"
             ToolTipText="Underline">
                 <toolbar:SfToolbarItem.Icon>
                     <FontImageSource Glyph="&#xE762;"
                          FontFamily="MauiMaterialAssets" />
                 </toolbar:SfToolbarItem.Icon>
             </toolbar:SfToolbarItem>
             <toolbar:SfToolbarItem Name="Italic"
             ToolTipText="Italic">
                 <toolbar:SfToolbarItem.Icon>
                     <FontImageSource Glyph="&#xE771;"
                          FontFamily="MauiMaterialAssets" />
                 </toolbar:SfToolbarItem.Icon>
             </toolbar:SfToolbarItem>
             <toolbar:SfToolbarItem Name="AlignLeft"
                        ToolTipText="Align-Left">
                 <toolbar:SfToolbarItem.Icon>
                     <FontImageSource Glyph="&#xE751;"
                          FontFamily="MauiMaterialAssets" />
                 </toolbar:SfToolbarItem.Icon>
             </toolbar:SfToolbarItem>
             <toolbar:SfToolbarItem Name="AlignRight"
                        ToolTipText="Align-Right">
                 <toolbar:SfToolbarItem.Icon>
                     <FontImageSource Glyph="&#xE753;"
              FontFamily="MauiMaterialAssets" />
                 </toolbar:SfToolbarItem.Icon>
             </toolbar:SfToolbarItem>
             <toolbar:SfToolbarItem Name="AlignCenter"
                        ToolTipText="Align-Center">
                 <toolbar:SfToolbarItem.Icon>
                     <FontImageSource Glyph="&#xE752;"
              FontFamily="MauiMaterialAssets" />
                 </toolbar:SfToolbarItem.Icon>
             </toolbar:SfToolbarItem>
             <toolbar:SfToolbarItem Name="AlignJustify"
                        ToolTipText="Align-Justify">
                 <toolbar:SfToolbarItem.Icon>
                     <FontImageSource Glyph="&#xE74F;"
              FontFamily="MauiMaterialAssets" />
                 </toolbar:SfToolbarItem.Icon>
             </toolbar:SfToolbarItem>
         </toolbar:SfToolbar.Items>
     </toolbar:SfToolbar>
 </VerticalStackLayout>
public partial class MainPage : ContentPage
 {
     public MainPage()
     {
         InitializeComponent();
         SfToolbar toolbar = new SfToolbar();
         toolbar.HeightRequest = 56;
         toolbar.WidthRequest = 270;
         toolbar.OverflowMode = ToolbarItemOverflowMode.NavigationButtons;
         toolbar.ForwardButtonIconColor = Colors.Red;
         toolbar.BackwardButtonIconColor = Colors.Red;
         toolbar.ForwardButtonBackground = Colors.Aqua;
         toolbar.BackwardButtonBackground = Colors.Aqua;

         ObservableCollection<BaseToolbarItem> itemCollection = new ObservableCollection<BaseToolbarItem>();

         itemCollection.Add(new SfToolbarItem
         {
             Name = "Bold",
             ToolTipText = "Bold",
             Icon = new FontImageSource { Glyph = "\uE770", FontFamily = "MauiMaterialAssets" }
         });

         itemCollection.Add(new SfToolbarItem
         {
             Name = "Underline",
             ToolTipText = "Underline",
             Icon = new FontImageSource { Glyph = "\uE762", FontFamily = "MauiMaterialAssets" }
         });

         itemCollection.Add(new SfToolbarItem
         {
             Name = "Italic",
             ToolTipText = "Italic",
             Icon = new FontImageSource { Glyph = "\uE771", FontFamily = "MauiMaterialAssets" }
         });

         itemCollection.Add(new SfToolbarItem
         {
             Name = "AlignLeft",
             ToolTipText = "Align-Left",
             Icon = new FontImageSource { Glyph = "\uE751", FontFamily = "MauiMaterialAssets" }
         });

         itemCollection.Add(new SfToolbarItem
         {
             Name = "AlignRight",
             ToolTipText = "Align-Right",
             Icon = new FontImageSource { Glyph = "\uE753", FontFamily = "MauiMaterialAssets" }
         });

         itemCollection.Add(new SfToolbarItem
         {
             Name = "AlignCenter",
             ToolTipText = "Align-Center",
             Icon = new FontImageSource { Glyph = "\uE752", FontFamily = "MauiMaterialAssets" }
         });

         itemCollection.Add(new SfToolbarItem
         {
             Name = "AlignJustify",
             ToolTipText = "Align-Justify",
             Icon = new FontImageSource { Glyph = "\uE74F", FontFamily = "MauiMaterialAssets" }
         });

         toolbar.Items = itemCollection;
         this.Content = toolbar;
     }
 }

navigation-button-customization

More Button Customization

The toolbar control supports customization of more button using properties MoreButtonIconColor, MoreButtonBackground.

  • MoreButtonIconColor : This property is used to customize the icon color of the more button.
  • MoreButtonBackground : This property is used to customize the background color of the more button.

The following code sample demonstrates how to create a toolbar control with more button customization.

<VerticalStackLayout>
    <toolbar:SfToolbar x:Name="Toolbar" HeightRequest="56" WidthRequest="270" OverflowMode="MoreButton" MoreButtonIconColor="Red" MoreButtonBackground="Yellow">
        <toolbar:SfToolbar.Items>
            <toolbar:SfToolbarItem Name="Bold"
         ToolTipText="Bold">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE770;"
                      FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Underline"
         ToolTipText="Underline">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE762;"
                      FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Italic"
         ToolTipText="Italic">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE771;"
                      FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignLeft"
                    ToolTipText="Align-Left">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE751;"
                      FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignRight"
                    ToolTipText="Align-Right">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE753;"
          FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignCenter"
                    ToolTipText="Align-Center">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE752;"
          FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignJustify"
                    ToolTipText="Align-Justify">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE74F;"
          FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
        </toolbar:SfToolbar.Items>
    </toolbar:SfToolbar>
 </VerticalStackLayout>
public partial class MainPage : ContentPage
{
    public MainPage()
    {
        InitializeComponent();
        SfToolbar toolbar = new SfToolbar();
        toolbar.HeightRequest = 56;
        toolbar.WidthRequest = 270;
        toolbar.OverflowMode = ToolbarItemOverflowMode.MoreButton;
        toolbar.MoreButtonIconColor = Colors.Red;
        toolbar.MoreButtonBackground = Colors.Red;


        ObservableCollection<BaseToolbarItem> itemCollection = new ObservableCollection<BaseToolbarItem>();

        itemCollection.Add(new SfToolbarItem
        {
            Name = "Bold",
            ToolTipText = "Bold",
            Icon = new FontImageSource { Glyph = "\uE770", FontFamily = "MauiMaterialAssets" }
        });

        itemCollection.Add(new SfToolbarItem
        {
            Name = "Underline",
            ToolTipText = "Underline",
            Icon = new FontImageSource { Glyph = "\uE762", FontFamily = "MauiMaterialAssets" }
        });

        itemCollection.Add(new SfToolbarItem
        {
            Name = "Italic",
            ToolTipText = "Italic",
            Icon = new FontImageSource { Glyph = "\uE771", FontFamily = "MauiMaterialAssets" }
        });

        itemCollection.Add(new SfToolbarItem
        {
            Name = "AlignLeft",
            ToolTipText = "Align-Left",
            Icon = new FontImageSource { Glyph = "\uE751", FontFamily = "MauiMaterialAssets" }
        });

        itemCollection.Add(new SfToolbarItem
        {
            Name = "AlignRight",
            ToolTipText = "Align-Right",
            Icon = new FontImageSource { Glyph = "\uE753", FontFamily = "MauiMaterialAssets" }
        });

        itemCollection.Add(new SfToolbarItem
        {
            Name = "AlignCenter",
            ToolTipText = "Align-Center",
            Icon = new FontImageSource { Glyph = "\uE752", FontFamily = "MauiMaterialAssets" }
        });

        itemCollection.Add(new SfToolbarItem
        {
            Name = "AlignJustify",
            ToolTipText = "Align-Justify",
            Icon = new FontImageSource { Glyph = "\uE74F", FontFamily = "MauiMaterialAssets" }
        });

        toolbar.Items = itemCollection;
        this.Content = toolbar;
    }
}

more-button-customization
