Overflow Mode in .NET MAUI Toolbar Control

This section explains the ways about how overflowing items are managed - Scroll for continuous navigation, NavigationButtons for stepping through items, and MoreButton to display excess items in a dropdown.

Scroll Mode

The Toolbar control enables scrolling when its items extend beyond the view. By default, the OverflowMode property is set to Scroll.

XAML
C#
<?xml version="1.0" encoding="utf-8" ?>
<ContentPage xmlns="http://schemas.microsoft.com/dotnet/2021/maui"
             xmlns:x="http://schemas.microsoft.com/winfx/2009/xaml"
             xmlns:local="clr-namespace:ToolbarSample"
             xmlns:toolbar="clr-namespace:Syncfusion.Maui.Toolbar;assembly=Syncfusion.Maui.Toolbar"
             x:Class="ToolbarSample.MainPage">
    <Grid>
    <toolbar:SfToolbar x:Name="Toolbar" HeightRequest="56" WidthRequest="220" OverflowMode="Scroll">
        <toolbar:SfToolbar.Items>
            <toolbar:SfToolbarItem Name="Bold"
                    ToolTipText="Bold">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE770;"
                                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Underline"
                    ToolTipText="Underline">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE762;"
                                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Italic"
                    ToolTipText="Italic">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE771;"
                                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignLeft"
                            ToolTipText="Align-Left">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE751;"
                                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignRight"
                            ToolTipText="Align-Right">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE753;"
                    FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignCenter"
                            ToolTipText="Align-Center">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE752;"
                    FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignJustify"
                            ToolTipText="Align-Justify">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE74F;"
                    FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
        </toolbar:SfToolbar.Items>
    </toolbar:SfToolbar>
    </Grid>
</ContentPage>
using Syncfusion.Maui.Toolbar;

namespace ToolbarSample
{
    public partial class MainPage : ContentPage
    {
        public MainPage()
        {
            InitializeComponent();

            SfToolbar toolbar = new SfToolbar();
            toolbar.HeightRequest = 56;
            toolbar.WidthRequest = 220;
            toolbar.OverflowMode = ToolbarItemOverflowMode.Scroll;
            ObservableCollection<BaseToolbarItem> itemCollection = new ObservableCollection<BaseToolbarItem>
            {
                new SfToolbarItem
                {
                    Name = "Bold",
                    ToolTipText = "Bold",
                    Icon = new FontImageSource { Glyph = "\uE770", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "Underline",
                    ToolTipText = "Underline",
                    Icon = new FontImageSource { Glyph = "\uE762", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "Italic",
                    ToolTipText = "Italic",
                    Icon = new FontImageSource { Glyph = "\uE771", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignLeft",
                    ToolTipText = "Align-Left",
                    Icon = new FontImageSource { Glyph = "\uE751", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignRight",
                    ToolTipText = "Align-Right",
                    Icon = new FontImageSource { Glyph = "\uE753", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignCenter",
                    ToolTipText = "Align-Center",
                    Icon = new FontImageSource { Glyph = "\uE752", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignJustify",
                    ToolTipText = "Align-Justify",
                    Icon = new FontImageSource { Glyph = "\uE74F", FontFamily = "MauiMaterialAssets" }
                }
            };
            toolbar.Items = itemCollection;
            this.Content = toolbar;
        }
    }
}

scroll-toolbar-items

Navigation Buttons

The Toolbar control provides support for navigating buttons to display the overflow items by setting the OverflowMode property to NavigationButtons.

XAML
C#
<?xml version="1.0" encoding="utf-8" ?>
<ContentPage xmlns="http://schemas.microsoft.com/dotnet/2021/maui"
             xmlns:x="http://schemas.microsoft.com/winfx/2009/xaml"
             xmlns:local="clr-namespace:ToolbarSample"
             xmlns:syncfusion="clr-namespace:Syncfusion.Maui.Toolbar;assembly=Syncfusion.Maui.Toolbar"
             x:Class="ToolbarSample.MainPage">
<Grid>
    <toolbar:SfToolbar x:Name="Toolbar" HeightRequest="56" WidthRequest="220" OverflowMode="NavigationButtons">
        <toolbar:SfToolbar.Items>
            <toolbar:SfToolbarItem Name="Bold"
                    ToolTipText="Bold">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE770;"
                                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Underline"
                    ToolTipText="Underline">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE762;"
                                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Italic"
                    ToolTipText="Italic">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE771;"
                                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignLeft"
                            ToolTipText="Align-Left">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE751;"
                                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignRight"
                            ToolTipText="Align-Right">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE753;"
                    FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignCenter"
                            ToolTipText="Align-Center">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE752;"
                    FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignJustify"
                            ToolTipText="Align-Justify">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE74F;"
                    FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
        </toolbar:SfToolbar.Items>
    </toolbar:SfToolbar>
    </Grid>
</ContentPage>
using Syncfusion.Maui.Toolbar;

namespace ToolbarSample
{
    public partial class MainPage : ContentPage
    {
        public MainPage()
        {
            InitializeComponent();

            SfToolbar toolbar = new SfToolbar();
            toolbar.HeightRequest = 56;
            toolbar.WidthRequest = 220;
            toolbar.OverflowMode = ToolbarItemOverflowMode.NavigationButtons;
            ObservableCollection<BaseToolbarItem> itemCollection = new ObservableCollection<BaseToolbarItem>
            {
                new SfToolbarItem
                {
                    Name = "Bold",
                    ToolTipText = "Bold",
                    Icon = new FontImageSource { Glyph = "\uE770", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "Underline",
                    ToolTipText = "Underline",
                    Icon = new FontImageSource { Glyph = "\uE762", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "Italic",
                    ToolTipText = "Italic",
                    Icon = new FontImageSource { Glyph = "\uE771", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignLeft",
                    ToolTipText = "Align-Left",
                    Icon = new FontImageSource { Glyph = "\uE751", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignRight",
                    ToolTipText = "Align-Right",
                    Icon = new FontImageSource { Glyph = "\uE753", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignCenter",
                    ToolTipText = "Align-Center",
                    Icon = new FontImageSource { Glyph = "\uE752", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignJustify",
                    ToolTipText = "Align-Justify",
                    Icon = new FontImageSource { Glyph = "\uE74F", FontFamily = "MauiMaterialAssets" }
                }
            };
            toolbar.Items = itemCollection;
            this.Content = toolbar;
        }
    }
}

More Items Menu

The Toolbar control displays additional items in a dropdown menu when they extend beyond the view. This can be enabled by setting the OverflowMode property to MoreButton.

The following code sample demonstrates how to display more items in the overflow menu.

XAML
C#
<?xml version="1.0" encoding="utf-8" ?>
<ContentPage xmlns="http://schemas.microsoft.com/dotnet/2021/maui"
             xmlns:x="http://schemas.microsoft.com/winfx/2009/xaml"
             xmlns:local="clr-namespace:ToolbarSample"
             xmlns:syncfusion="clr-namespace:Syncfusion.Maui.Toolbar;assembly=Syncfusion.Maui.Toolbar"
             x:Class="ToolbarSample.MainPage">
    <Grid>
        <toolbar:SfToolbar x:Name="Toolbar" HeightRequest="56" WidthRequest="220" OverflowMode="MoreButton">
        <toolbar:SfToolbar.Items>
            <toolbar:SfToolbarItem Name="Bold"
                ToolTipText="Bold">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE770;"
                            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Underline"
                ToolTipText="Underline">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE762;"
                            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Italic"
                ToolTipText="Italic">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE771;"
                            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignLeft"
                        ToolTipText="Align-Left">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE751;"
                            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignRight"
                        ToolTipText="Align-Right">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE753;"
                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignCenter"
                        ToolTipText="Align-Center">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE752;"
                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignJustify"
                        ToolTipText="Align-Justify">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE74F;"
                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
        </toolbar:SfToolbar.Items>
    </toolbar:SfToolbar>
    </Grid>
</ContentPage>
using Syncfusion.Maui.Toolbar;

namespace ToolbarSample
{
    public partial class MainPage : ContentPage
    {
        public MainPage()
        {
            InitializeComponent();

            SfToolbar toolbar = new SfToolbar();
            toolbar.HeightRequest = 56;
            toolbar.WidthRequest = 220;
            toolbar.OverflowMode = ToolbarItemOverflowMode.MoreButton;

            ObservableCollection<BaseToolbarItem> itemCollection = new ObservableCollection<BaseToolbarItem>
            {
                new SfToolbarItem
                {
                    Name = "Bold",
                    ToolTipText = "Bold",
                    Icon = new FontImageSource { Glyph = "\uE770", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "Underline",
                    ToolTipText = "Underline",
                    Icon = new FontImageSource { Glyph = "\uE762", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "Italic",
                    ToolTipText = "Italic",
                    Icon = new FontImageSource { Glyph = "\uE771", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignLeft",
                    ToolTipText = "Align-Left",
                    Icon = new FontImageSource { Glyph = "\uE751", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignRight",
                    ToolTipText = "Align-Right",
                    Icon = new FontImageSource { Glyph = "\uE753", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignCenter",
                    ToolTipText = "Align-Center",
                    Icon = new FontImageSource { Glyph = "\uE752", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignJustify",
                    ToolTipText = "Align-Justify",
                    Icon = new FontImageSource { Glyph = "\uE74F", FontFamily = "MauiMaterialAssets" }
                }
            };

            toolbar.Items = itemCollection;
            this.Content = toolbar;
        }
    }
}

More Items Menu Position

The Toolbar control provides support for changing the position of the More button using the MoreItemsRelativePosition property. The default value of this property is Auto. You can change the position of the More button by setting the MoreItemsRelativePosition property to Left, Right, Top, or Bottom.

XAML
C#
<?xml version="1.0" encoding="utf-8" ?>
<ContentPage xmlns="http://schemas.microsoft.com/dotnet/2021/maui"
             xmlns:x="http://schemas.microsoft.com/winfx/2009/xaml"
             xmlns:local="clr-namespace:ToolbarSample"
             xmlns:syncfusion="clr-namespace:Syncfusion.Maui.Toolbar;assembly=Syncfusion.Maui.Toolbar"
             x:Class="ToolbarSample.MainPage">
        <Grid>
        <toolbar:SfToolbar x:Name="Toolbar" HeightRequest="56" WidthRequest="220" OverflowMode="MoreButton" MoreItemsRelativePosition="Right">
        <toolbar:SfToolbar.Items>
            <toolbar:SfToolbarItem Name="Bold"
                ToolTipText="Bold">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE770;"
                            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Underline"
                ToolTipText="Underline">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE762;"
                            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="Italic"
                ToolTipText="Italic">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE771;"
                            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignLeft"
                        ToolTipText="Align-Left">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE751;"
                            FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignRight"
                        ToolTipText="Align-Right">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE753;"
                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignCenter"
                        ToolTipText="Align-Center">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE752;"
                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
            <toolbar:SfToolbarItem Name="AlignJustify"
                        ToolTipText="Align-Justify">
                <toolbar:SfToolbarItem.Icon>
                    <FontImageSource Glyph="&#xE74F;"
                FontFamily="MauiMaterialAssets" />
                </toolbar:SfToolbarItem.Icon>
            </toolbar:SfToolbarItem>
        </toolbar:SfToolbar.Items>
    </toolbar:SfToolbar>
    </Grid>
</ContentPage>
using Syncfusion.Maui.Toolbar;

namespace ToolbarSample
{
    public partial class MainPage : ContentPage
    {
        public MainPage()
        {
            InitializeComponent();

            SfToolbar toolbar = new SfToolbar();
            toolbar.HeightRequest = 56;
            toolbar.WidthRequest = 220;
            toolbar.OverflowMode = ToolbarItemOverflowMode.MoreButton;
            toolbar.MoreItemsRelativePosition = ToolbarRelativePosition.Right;

            ObservableCollection<BaseToolbarItem> itemCollection = new ObservableCollection<BaseToolbarItem>
            {
                new SfToolbarItem
                {
                    Name = "Bold",
                    ToolTipText = "Bold",
                    Icon = new FontImageSource { Glyph = "\uE770", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "Underline",
                    ToolTipText = "Underline",
                    Icon = new FontImageSource { Glyph = "\uE762", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "Italic",
                    ToolTipText = "Italic",
                    Icon = new FontImageSource { Glyph = "\uE771", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignLeft",
                    ToolTipText = "Align-Left",
                    Icon = new FontImageSource { Glyph = "\uE751", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignRight",
                    ToolTipText = "Align-Right",
                    Icon = new FontImageSource { Glyph = "\uE753", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignCenter",
                    ToolTipText = "Align-Center",
                    Icon = new FontImageSource { Glyph = "\uE752", FontFamily = "MauiMaterialAssets" }
                },
                new SfToolbarItem
                {
                    Name = "AlignJustify",
                    ToolTipText = "Align-Justify",
                    Icon = new FontImageSource { Glyph = "\uE74F", FontFamily = "MauiMaterialAssets" }
                }
            };

            toolbar.Items = itemCollection;
            this.Content = toolbar;
        }
    }
}

The In-build more items drop down menu view can be cancelled with the help of Cancel parameter in the MoreButtonTapped event.

MainPage.xaml
MainPage.xaml.cs
<toolbar:SfToolbar x:Name="Toolbar"
                    HeightRequest="56"
                    WidthRequest="220"
                    MoreButtonTapped="OnMoreButtonTapped"
                    OverflowMode="MoreButton">
</toolbar:SfToolbar>
this.toolbar.MoreButtonTapped += this.OnMoreButtonTapped;
private void OnMoreButtonTapped(object? sender, ToolbarMoreButtonTappedEventArgs e)
{
    e.Cancel = true;
    var moreItems = e.ToolbarItems;
}

Overflow Mode in .NET MAUI Toolbar (SfToolbar)

Scroll Mode

Navigation Buttons

More Items Menu

More Items Menu Position

Cancel the default item dropdown view
