Getting Started with .NET MAUI ComboBox

17 Sep 202412 minutes to read

This section guides you through setting up and configuring a ComboBox in your .NET MAUI application. Follow the steps below to add a basic ComboBox to your project.

To quickly get started with the .NET MAUI ComboBox, watch this video.

Prerequisites

Before proceeding, ensure the following are in place:

  1. Install .NET 7 SDK or later.
  2. Set up a .NET MAUI environment with Visual Studio 2022 (v17.3 or later) or Visual Studio Code. For Visual Studio Code users, ensure that the .NET MAUI workload is installed and configured as described here.

Step 1: Create a New MAUI Project

Visual Studio

  1. Go to File > New > Project and choose the .NET MAUI App template.
  2. Name the project and choose a location. Then, click Next.
  3. Select the .NET framework version and click Create.

Visual Studio Code

  1. Open the Command Palette by pressing Ctrl+Shift+P and type .NET:New Project and press Enter.
  2. Choose the .NET MAUI App template.
  3. Select the project location, type the project name and press Enter.
  4. Then choose Create project

Step 2: Install the Syncfusion MAUI Inputs NuGet Package

  1. In Solution Explorer, right-click the project and choose Manage NuGet Packages.
  2. Search for Syncfusion.Maui.Inputs and install the latest version.
  3. Ensure the necessary dependencies are installed correctly, and the project is restored.

Step 3: Register the handler

Syncfusion.Maui.Core nuget is a dependent package for all Syncfusion controls of .NET MAUI. In the MauiProgram.cs file, register the handler for Syncfusion core.

  • C#
    • using Microsoft.Maui;
using Microsoft.Maui.Hosting;
using Microsoft.Maui.Controls.Compatibility;
using Microsoft.Maui.Controls.Hosting;
using Microsoft.Maui.Controls.Xaml;
using Syncfusion.Maui.Core.Hosting;

namespace ComboBoxSample
{
    public static class MauiProgram
    {
        public static MauiApp CreateMauiApp()
        {
            var builder = MauiApp.CreateBuilder();
            builder
            .UseMauiApp<App>()
            .ConfigureSyncfusionCore()
            .ConfigureFonts(fonts =>
            {
                fonts.AddFont("OpenSans-Regular.ttf", "OpenSansRegular");
            });

            return builder.Build();
        }
    }
}

    Step 4: Add a Basic ComboBox

    The .NET MAUI ComboBox control is configured entirely in C# code or by using XAML markup. The following steps explain how to create a .NET MAUI ComboBox (SfComboBox) and configure its elements:

    Adding the .NET MAUI ComboBox control

    Step 1: Add the NuGet to the project as discussed in the above reference section.

    Step 2: Add the namespace as shown in the following code sample:

    xmlns:editors="clr-namespace:Syncfusion.Maui.Inputs;assembly=Syncfusion.Maui.Inputs"
    using Syncfusion.Maui.Inputs;

    Step 3: Set the control to content in ContentPage.

    <ContentPage.Content>
    <editors:SfComboBox x:Name="comboBox" />
</ContentPage.Content>
    SfComboBox comboBox = new SfComboBox();
Content = comboBox;

    Step 5: Populate items using data binding

    The ComboBox can be bound to an external data source using the ItemsSource property. Now, let us create Model and ViewModel classes to populate ComboBox with SocialMedia details.

    Step 1: Define a simple model class SocialMedia with fields ID and name, and then populate social media data in the ViewModel.

    //Model.cs
public class SocialMedia
{
    public string Name { get; set; }
    public int ID { get; set; }
}

//ViewModel.cs
public class SocialMediaViewModel
{
    public ObservableCollection<SocialMedia> SocialMedias { get; set; }
    public SocialMediaViewModel()
    {
        this.SocialMedias = new ObservableCollection<SocialMedia>();
        this.SocialMedias.Add(new SocialMedia() { Name = "Facebook", ID = 0 });
        this.SocialMedias.Add(new SocialMedia() { Name = "Google Plus", ID = 1 });
        this.SocialMedias.Add(new SocialMedia() { Name = "Instagram", ID = 2 });
        this.SocialMedias.Add(new SocialMedia() { Name = "LinkedIn", ID = 3 });
        this.SocialMedias.Add(new SocialMedia() { Name = "Skype", ID = 4 });
        this.SocialMedias.Add(new SocialMedia() { Name = "Telegram", ID = 5 });
        this.SocialMedias.Add(new SocialMedia() { Name = "Televzr", ID = 6 });
        this.SocialMedias.Add(new SocialMedia() { Name = "Tik Tok", ID = 7 });
        this.SocialMedias.Add(new SocialMedia() { Name = "Tout", ID = 8 });
        this.SocialMedias.Add(new SocialMedia() { Name = "Tumblr", ID = 9 });
        this.SocialMedias.Add(new SocialMedia() { Name = "Twitter", ID = 10 });
        this.SocialMedias.Add(new SocialMedia() { Name = "Vimeo", ID = 11 });
        this.SocialMedias.Add(new SocialMedia() { Name = "WhatsApp", ID = 12 });
        this.SocialMedias.Add(new SocialMedia() { Name = "YouTube", ID = 13 });
    }
}

    Step 2: Populate data in ComboBox.

    Now, populate this SocialMediaViewModel data in ComboBox control by binding it to the ItemsSource property.

    <?xml version="1.0" encoding="utf-8" ?>
<ContentPage xmlns="http://schemas.microsoft.com/dotnet/2021/maui"
             xmlns:x="http://schemas.microsoft.com/winfx/2009/xaml"
             xmlns:editors="clr-namespace:Syncfusion.Maui.Inputs;assembly=Syncfusion.Maui.Inputs"
             xmlns:local="clr-namespace:ComboBoxSample"
             x:Class="ComboBoxSample.MainPage">

       <ContentPage.BindingContext>
            <local:SocialMediaViewModel />
       </ContentPage.BindingContext>

       <ContentPage.Content>
            <!--Setting ItemsSource-->
            <editors:SfComboBox x:Name="comboBox"
                                WidthRequest="250"
                                HeightRequest="50"
                                ItemsSource="{Binding SocialMedias}" />
        </ContentPage.Content>
</ContentPage>
    SocialMediaViewModel socialMediaViewModel = new SocialMediaViewModel();
this.BindingContext = socialMediaViewModel;
SfComboBox comboBox = new SfComboBox();
comboBox.WidthRequest = 250;
comboBox.HeightRequest = 50;
comboBox.ItemsSource = socialMediaViewModel.SocialMedias;
Content = comboBox;

    NOTE

    Set the BindingContext of your page to an instance of SocialMediaViewModel. This allows you to bind the properties of SocialMediaViewModel to the ComboBox control.

    Step 3: Setting TextMemberPath and DisplayMemberPath.

    The ComboBox control is populated with a list of social media. But the SocialMedia model contains two properties, ID and Name, so it is necessary to intimate by which property it should display the value in the selection box portion of the `ComboBox control when an item is selected.

    TextMemberPath - This property path is used to get the value for displaying in the selection box portion of the ComboBox control when an item is selected. The default value is String.Empty.

    DisplayMemberPath - This property path is used to the name or path of the property displayed for each data item in the drop-down list. The default value is String.Empty.

    <editors:SfComboBox x:Name="comboBox"
                    WidthRequest="250"
                    HeightRequest = "50"
                    DisplayMemberPath = "Name"
                    TextMemberPath = "Name"
                    ItemsSource="{Binding SocialMedias}" />
    SfComboBox comboBox = new SfComboBox();
comboBox.WidthRequest = 250;
comboBox.HeightRequest = 50;
comboBox.DisplayMemberPath = "Name";
comboBox.TextMemberPath = "Name";
comboBox.ItemsSource = socialMediaViewModel.SocialMedias;

    The following gif image illustrates the result of the above code:

    .NET MAUI ComboBox populating using data binding

    Editing

    The ComboBox control supports editable and non-editable modes to choose items. To enable the editing functionality, set the IsEditable property as true. The default value is false.

    <editors:SfComboBox x:Name="comboBox"
                    WidthRequest="250"
                    HeightRequest="50"
                    IsEditable="true"
                    ItemsSource="{Binding SocialMedias}"
                    DisplayMemberPath="Name"
                    TextMemberPath="Name">
</editors:SfComboBox>
    SfComboBox comboBox = new SfComboBox();
comboBox.WidthRequest = 250;
comboBox.HeightRequest = 50;
comboBox.IsEditable = true;
comboBox.ItemsSource = socialMediaViewModel.SocialMedias;
comboBox.DisplayMemberPath = "Name";
comboBox.TextMemberPath = "Name";

    The following gif image illustrates the result of the above code:

    .NET MAUI ComboBox choose item using editing

    You can find the complete getting started sample of .NET MAUI ComboBox from this link.

    Text

    The Text property is used to get the user-submitted text in the SfComboBox editable mode. The default value of the Text property is string.Empty.

    NOTE

    You can refer to our .NET MAUI ComboBox feature tour page for its groundbreaking feature representations. You can also explore our .NET MAUI ComboBox Example that shows you how to render the ComboBox in .NET MAUI.
