Getting Started with the Vue 3D Circular Chart Component in Vue 3

This article provides a step-by-step guide to setting up a Vite JavaScript project and integrating the Syncfusion^® Vue 3D Circular Chart component using either the Composition API or the Options API.

The Composition API groups related logic into reusable functions. The Options API organizes component logic with options such as data, methods, and life cycle hooks. Choose the API that best fits the application’s structure.

Prerequisites

Ensure that the development environment meets the system requirements for Syncfusion Vue UI components.

Set Up the Vite Project

Create a Vite project using either npm or yarn.

npm

npm create vite@latest my-app -- --template vue

yarn

yarn create vite my-app --template vue

If Vite prompts you to install dependencies and start the project immediately, select No. The Syncfusion package is installed in a later step.

Navigate to the project folder:

cd my-app

Install the application dependencies using npm or yarn:

npm

npm install

yarn

yarn install

Note If you prefer TypeScript instead of JavaScript, create the application using npm create vite@latest my-app – –template vue-ts.

Add the Syncfusion^® Vue Package

Syncfusion Vue packages are available on npm.

Install the @syncfusion/ej2-vue-charts package. Use a package release compatible with Vue 3 and the Node.js version used by the project.

npm

npm install @syncfusion/ej2-vue-charts

yarn

yarn add @syncfusion/ej2-vue-charts

Note: For TypeScript projects, refer to Vue 3 with the Composition API and TypeScript or Vue 3 with the Options API and TypeScript.

Add the Syncfusion^® Vue 3D Circular Chart Component

Follow these steps to add the Vue 3D Circular Chart component using the Composition API or Options API.

Step 1: Import and Register the Component

Import the 3D Circular Chart component, its child directives, and the feature modules used by the example in src/App.vue.

The example uses the following modules:

PieSeries3D renders the 3D pie series.

In the Composition API example, alias the component and directive imports to names that match the custom elements in the template. Components imported in <script setup> are available directly in the template.

Composition API (~/src/App.vue)
Options API (~/src/App.vue)
<script setup>
import { provide } from 'vue';
import {
  CircularChart3DComponent as EjsCircularchart3d,
  CircularChart3DSeriesCollectionDirective as ECircularchart3dSeriesCollection,
  CircularChart3DSeriesDirective as ECircularchart3dSeries,
  PieSeries3D
} from '@syncfusion/ej2-vue-charts';

provide('circularchart3d', [
  PieSeries3D
]);
</script>
<script>
import {
  CircularChart3DComponent,
  CircularChart3DSeriesCollectionDirective,
  CircularChart3DSeriesDirective,
  PieSeries3D
} from '@syncfusion/ej2-vue-charts';

export default {
  name: 'App',
  components: {
    'ejs-circularchart3d': CircularChart3DComponent,
    'e-circularchart3d-series-collection': CircularChart3DSeriesCollectionDirective,
    'e-circularchart3d-series': CircularChart3DSeriesDirective
  },
  provide: {
    circularchart3d: [
      PieSeries3D
    ]
  }
};
</script>

Note: The module injection key must be circularchart3d. Register only the modules required by the features used in the application.

Step 2: Declare the Data and Configuration

Define the series data and the chart configuration values in the script section.

Composition API (~/src/App.vue)
Options API (~/src/App.vue)
<script setup>
const seriesData = [
  { browser: 'Chrome', share: 64.2 },
  { browser: 'Safari', share: 18.8 },
  { browser: 'Edge', share: 4.9 },
  { browser: 'Firefox', share: 3.1 },
  { browser: 'Opera', share: 2.4 },
  { browser: 'Others', share: 6.6 }
];

const title = 'Sample Browser Distribution';
const tilt = 30;
</script>
<script>
export default {
  data() {
    return {
      seriesData: [
        { browser: 'Chrome', share: 64.2 },
        { browser: 'Safari', share: 18.8 },
        { browser: 'Edge', share: 4.9 },
        { browser: 'Firefox', share: 3.1 },
        { browser: 'Opera', share: 2.4 },
        { browser: 'Others', share: 6.6 }
      ],
      title: 'Sample Browser Distribution',
      tilt: 30
    };
  }
};
</script>

Step 3: Define the 3D Circular Chart in the Template

Add the 3D Circular Chart and its series directives to the template section of src/App.vue.

The series uses the following properties:

dataSource specifies the array of data objects.
xName maps the category field.
yName maps the numeric value field.
title specifies the chart title.
tilt specifies the vertical rotation of the 3D chart.

~/src/App.vue
<template>
  <div id="app">
    <ejs-circularchart3d
      id="container"
      :title="title"
      :tilt="tilt"
    >
      <e-circularchart3d-series-collection>
        <e-circularchart3d-series
          :dataSource="seriesData"
          xName="browser"
          yName="share"
        ></e-circularchart3d-series>
      </e-circularchart3d-series-collection>
    </ejs-circularchart3d>
  </div>
</template>

Each data object must contain the fields assigned to xName and yName. The field assigned to yName must contain a numeric value.

Here is the summarized code for the above steps in the src/App.vue file.

Replace the contents of src/App.vue with either the Composition API or Options API example.

Composition API (~/src/App.vue)
Options API (~/src/App.vue)
<template>
  <div id="app">
    <ejs-circularchart3d
      id="container"
      :title="title"
      :tilt="tilt"
    >
      <e-circularchart3d-series-collection>
        <e-circularchart3d-series
          :dataSource="seriesData"
          xName="browser"
          yName="share"
        ></e-circularchart3d-series>
      </e-circularchart3d-series-collection>
    </ejs-circularchart3d>
  </div>
</template>

<script setup>
import { provide } from 'vue';
import {
  CircularChart3DComponent as EjsCircularchart3d,
  CircularChart3DSeriesCollectionDirective as ECircularchart3dSeriesCollection,
  CircularChart3DSeriesDirective as ECircularchart3dSeries,
  PieSeries3D
} from '@syncfusion/ej2-vue-charts';

const seriesData = [
  { browser: 'Chrome', share: 64.2 },
  { browser: 'Safari', share: 18.8 },
  { browser: 'Edge', share: 4.9 },
  { browser: 'Firefox', share: 3.1 },
  { browser: 'Opera', share: 2.4 },
  { browser: 'Others', share: 6.6 }
];

const title = 'Sample Browser Distribution';
const tilt = 30;
provide('circularchart3d', [
  PieSeries3D
]);
</script>
<template>
  <div id="app">
    <ejs-circularchart3d
      id="container"
      :title="title"
      :tilt="tilt"
    >
      <e-circularchart3d-series-collection>
        <e-circularchart3d-series
          :dataSource="seriesData"
          xName="browser"
          yName="share"
        ></e-circularchart3d-series>
      </e-circularchart3d-series-collection>
    </ejs-circularchart3d>
  </div>
</template>

<script>
import {
  CircularChart3DComponent,
  CircularChart3DSeriesCollectionDirective,
  CircularChart3DSeriesDirective,
  PieSeries3D
} from '@syncfusion/ej2-vue-charts';

export default {
  name: 'App',
  components: {
    'ejs-circularchart3d': CircularChart3DComponent,
    'e-circularchart3d-series-collection': CircularChart3DSeriesCollectionDirective,
    'e-circularchart3d-series': CircularChart3DSeriesDirective
  },
  provide: {
    circularchart3d: [
      PieSeries3D
    ]
  },
  data() {
    return {
      seriesData: [
        { browser: 'Chrome', share: 64.2 },
        { browser: 'Safari', share: 18.8 },
        { browser: 'Edge', share: 4.9 },
        { browser: 'Firefox', share: 3.1 },
        { browser: 'Opera', share: 2.4 },
        { browser: 'Others', share: 6.6 }
      ],
      title: 'Sample Browser Distribution',
      tilt: 30
    };
  }
};
</script>

Run the Project

Save src/App.vue, and then start the development server using either npm or yarn.

npm

npm run dev

yarn

yarn run dev

Open the local URL displayed in the terminal, commonly http://localhost:5173, and verify that a 3D pie chart titled Sample Browser Distribution displays six categories.

Vue 3 3D Circular Chart

Troubleshooting

The 3D Circular Chart is not rendered. Verify that the component and both child directives are imported. In the Options API, also verify that they are registered in components. Check the browser console for component, module, data, or licensing errors.
The pie series is not displayed. Import PieSeries3D and include it in the array provided with the exact circularchart3d key.
No data is displayed. Verify that dataSource contains records, xName and yName match fields in every data object, and the field mapped by yName contains numeric values.
The Composition API template does not recognize the component. Verify that the imported component and directives use aliases matching the template element names.
An import or runtime error is displayed. Verify that @syncfusion/ej2-vue-charts is installed and that its version supports the project’s Vue and Node.js versions.

For additional assistance, refer to the Vue 3D Circular Chart API documentation.
