How to Insert Text or Image in Table in JavaScript DOCX Editor

28 Aug 20263 minutes to read

Using JavaScript DOCX Editor (Document Editor) APIs, you can insert text or an image in a table programmatically based on your requirements.

Use the selection APIs to navigate between rows and cells.

The following example illustrates how to create a 2x2 table and then add text and an image programmatically.

import { DocumentEditorContainer, Toolbar } from '@syncfusion/ej2-documenteditor';

DocumentEditorContainer.Inject(Toolbar);

let container: DocumentEditorContainer = new DocumentEditorContainer({ enableToolbar: true, height: '590px' });

container.serviceUrl = 'https://document.syncfusion.com/web-services/docx-editor/api/documenteditor/';

container.appendTo('#container');
// To insert the table at the cursor position
container.documentEditor.editor.insertTable(2, 2);
// To insert the image at the first cell of the table
// To move the cursor to the next cell
moveCursorToNextCell();
// To insert the image at the second cell of the table
// To move the cursor to the next row
moveCursorToNextRow();
// To insert text at the cursor position
container.documentEditor.editor.insertText('Text');
// To move the cursor to the next cell
moveCursorToNextCell();
// To insert text at the cursor position
container.documentEditor.editor.insertText('Text');

function moveCursorToNextCell() {
// To get the current selection start offset
var startOffset = container.documentEditor.selection.startOffset;
// Increasing the cell index to consider the next cell
var cellIndex = parseInt(startOffset.substring(6, 7)) + 1;
// Changing the start offset
startOffset = startOffset.substring(0, 6) + cellIndex.toString() + startOffset.substring(7, startOffset.length);
// Navigating the selection using the select method
container.documentEditor.selection.select(startOffset, startOffset);
}

function moveCursorToNextRow() {
// To get the current selection start offset
var startOffset = container.documentEditor.selection.startOffset;
// Increasing the row index to consider the next row
var rowIndex = parseInt(startOffset.substring(4, 5)) + 1;
var cellIndex = parseInt(startOffset.substring(6, 7)) != 0 ? parseInt(startOffset.substring(6, 7)) - 1 : 0;
// Changing the start offset
startOffset = startOffset.substring(0, 4) + rowIndex.toString() + startOffset.substring(5, 6) + cellIndex + startOffset.substring(7, startOffset.length);
// Navigating the selection using the select method
container.documentEditor.selection.select(startOffset, startOffset);
}

The Web API hosted link https://document.syncfusion.com/web-services/docx-editor/api/documenteditor/ utilized in the DOCX Editor’s serviceUrl property is intended solely for demonstration and evaluation purposes. For production deployment, please host your own web service with your required server configurations. You can refer and reuse the GitHub Web Service example or Docker image for hosting your own web service and use for the serviceUrl property.

The output will be as shown below.
Insert text or image in table programmatically
