Excel Export in ASP.NET Core Tree Grid Component

The excel export allows exporting TreeGrid data to Excel document. You need to use the excelExport method for exporting. To enable Excel export in the treegrid, set the allowExcelExport as true.

Persist collapsed state

You can persist the collapsed state in the exported document by defining isCollapsedStatePersist property as true in TreeGridExcelExportProperties parameter of excelExport method.

Exporting custom aggregates in TreeGrid

The TreeGrid enables exporting custom aggregates, which summarize column data, to an Excel document using the excelAggregateQueryCellInfo event.

In the provided example, the customAggregateFn function computes the item count for a selected category, while the excelAggregateQueryCellInfo event customizes the exported cell values in the Excel document.

<ejs-treegrid id="TreeGrid" dataSource="@ViewBag.DataSource" childMapping="subtasks" treeColumnIndex="1" height="400" gridLines="Both" allowExcelExport="true" toolbar="@(new List<string>() { "ExcelExport", "CsvExport" })" dataBound="onDataBound" excelAggregateQueryCellInfo="formatExcelAggregateCell">
    <e-treegrid-columns>
        <e-treegrid-column field="ID" headerText="Order ID" width="115" textAlign="Left"></e-treegrid-column>
        <e-treegrid-column field="Name" headerText="Shipment Name" width="230" clipMode="EllipsisWithTooltip"></e-treegrid-column>
        <e-treegrid-column field="shipmentDate" headerText="Shipment Date" width="135" type="date" format="yMd" textAlign="Right"></e-treegrid-column>
        <e-treegrid-column field="category" headerText="Category" width="220" minWidth="210"></e-treegrid-column>
        <e-treegrid-column field="units" headerText="Total Units" width="90" type="number" textAlign="Right"></e-treegrid-column>
        <e-treegrid-column field="unitPrice" headerText="Unit Price($)" width="100" type="number" format="C2" textAlign="Right"></e-treegrid-column>
        <e-treegrid-column field="price" headerText="Price($)" width="140" type="number" format="C0" textAlign="Right"></e-treegrid-column>
    </e-treegrid-columns>

    <e-treegrid-aggregates>
        <e-treegrid-aggregate showChildSummary="false">
            <e-treegrid-aggregate-columns>
					<e-treegrid-aggregate-column type="Custom" columnName="category" format="C2" footerTemplate="<span>Count of <input type='text' id='customers' /> : ${Custom}</span>" customAggregate="customAggregateFn"></e-treegrid-aggregate-column>
            </e-treegrid-aggregate-columns>
        </e-treegrid-aggregate>
    </e-treegrid-aggregates>
</ejs-treegrid>

<script>
    var selectedCategory = 'Seafood';
    var categoryDropdown = null;

    var categoryOptions = [
        { food: 'Seafood' },
        { food: 'Dairy' },
        { food: 'Edible' },
        { food: 'Crystal' }
    ];

    function customAggregateFn(data) {
        var records = data.result ? ej.grids.getObject('result', data) : data;
        return records.reduce(function (count, item) {
            var category = ej.grids.getObject('category', item);
            return category === selectedCategory ? count + 1 : count;
        }, 0);
    }

    function formatExcelAggregateCell(args) {
        if (args.cell.column.headerText === 'Category') {
            args.style.value = 'Count of ' + selectedCategory + ' : ' + args.row.data.category.Custom;
        }
    }

    function onDataBound() {
        if (categoryDropdown && categoryDropdown.element && categoryDropdown.element.classList.contains('e-' + categoryDropdown.getModuleName())) { categoryDropdown.destroy();}

        categoryDropdown = new ej.dropdowns.DropDownList({
            dataSource: categoryOptions,
            fields: { value: 'food' },
            placeholder: 'Select a Category',
            width: '110px',
            value: selectedCategory,
            change: function () {
                setTimeout(function () {
                    if (categoryDropdown && categoryDropdown.value) {
                        selectedCategory = categoryDropdown.value.toString();
                        var treeGrid = document.getElementById('TreeGrid').ej2_instances[0];
                        treeGrid.refresh();
                    }
                }, 300);
            }
        });

        categoryDropdown.appendTo('#customers');
    }

    document.addEventListener('DOMContentLoaded', function () {
        var treeGrid = document.getElementById('TreeGrid').ej2_instances[0];
        treeGrid.customAggregate = customAggregateFn;
        treeGrid.excelAggregateQueryCellInfo = formatExcelAggregateCell;
        treeGrid.dataBound = onDataBound;
    });
</script>
public IActionResult Index()
{
    var tree = summaryData.GetDefaultData();
    ViewBag.datasource = tree;
    return View();
}

Excel Custom Aggregates

NOTE

You can refer to our ASP.NET Core Tree Grid feature tour page for its groundbreaking feature representations. You can also explore our ASP.NET Core Tree Grid example ASP.NET Core Tree Grid example to knows how to present and manipulate data.
