How to Insert Text or Image in Table in ASP.NET Core DOCX Editor

14 Aug 20263 minutes to read

Using the ASP.NET Core DOCX Editor (Document Editor) APIs, you can insert [text] or [image] in a [table] programmatically based on your requirement.

Use the [selection] APIs to navigate between rows and cells.

The following example illustrates how to create a 2x2 table and then add text and an image programmatically.

<div class="control-section">
    <ejs-documenteditorcontainer id="container" serviceUrl="/api/DocumentEditor/" enableToolbar=true created="onCreated" height="590px"></ejs-documenteditorcontainer>
</div>

<script>
    var documenteditor;
    var container;
    function onCreated() {
        var documenteditorElement = document.getElementById("container");
        container = documenteditorElement.ej2_instances[0];
        // To insert the table in cursor position
        container.documentEditor.editor.insertTable(2, 2);
        // To insert the image at table first cell
        // To move the cursor to next cell
        moveCursorToNextCell();
        // To insert the image at table second cell
        // To move the cursor to next row
        moveCursorToNextRow();
        // To insert text in cursor position
        container.documentEditor.editor.insertText('Text');
        // To move the cursor to next cell
        moveCursorToNextCell();
        // To insert text in cursor position
        container.documentEditor.editor.insertText('Text');
    }
function moveCursorToNextCell() {
  // To get current selection start offset
  var startOffset = container.documentEditor.selection.startOffset;
  // Increasing cell index to consider next cell
  var startOffsetArray = startOffset.split(';');
  startOffsetArray[3] = parseInt(startOffsetArray[3]) + 1;
  // Changing start offset
  startOffset = startOffsetArray.join(';');
  // Navigating selection using select method
  container.documentEditor.selection.select(startOffset, startOffset);
}

function moveCursorToNextRow() {
  // To get current selection start offset
  var startOffset = container.documentEditor.selection.startOffset;
  // Increasing row index to consider next row
  var startOffsetArray = startOffset.split(';');
  startOffsetArray[2] = parseInt(startOffsetArray[2]) + 1;
  // Going back to first cell
  startOffsetArray[3] = 0;
  // Changing start offset
  startOffset = startOffsetArray.join(';');
  // Navigating selection using select method
  container.documentEditor.selection.select(startOffset, startOffset);
}
  </script>

The output will be as shown below.

Insert text or image in table programmatically
