Collaborative Editing in Syncfusion Vue PDF Viewer

28 Oct 20263 minutes to read

The Vue PDF Viewer supports real-time collaborative editing through the Syncfusion Collaborator framework. The framework uses a shared client package and a platform-specific Collaboration Server to synchronize PDF Viewer actions between users.

Collaborative Editing in Angular PDF Viewer

Architecture

Collaborative editing uses the following components:

  • Collaboration Client - The @syncfusion/ej2-collaborator package connects the Vue PDF Viewer to the Collaboration Server.
  • PDF Viewer adapter - A client-side PdfViewerAdapter implements ICollaborationProvider and translates actions between the PDF Viewer and the Collaboration Client.
  • Collaboration Server - Use ej2-collaborator-server for Node.js, or Syncfusion.Collaborator.Server.AspNet.Core for ASP.NET Core.
  • Redis - Required by the Collaboration Server for operation storage, synchronization, and scale-out.

The Collaboration Server manages the transport, collaboration sessions, operation synchronization, and save processing. The PDF Viewer application supplies the control adapter and document routes. Do not add a separate Socket.IO Redis adapter or implement the collaboration operation queue in the PDF Viewer application.

Collaborative features

Users can collaborate on the same PDF room and see shared changes to:

  • Annotations - Comments, highlights, drawings, and stamps
  • Form field interactions - Form field changes and value updates
  • Page Organizer operations - Page reordering, page rotation, and page changes

Prerequisites

  • A Vue PDF Viewer application.
  • A Redis instance reachable from the server.
  • Node.js 18 or later.
  • A PDF Viewer adapter on the client and server. The adapter is the control-specific bridge; the common Collaborator packages provide the collaboration infrastructure.

Client package

Install the shared client package in the Vue application:

npm install @syncfusion/ej2-collaborator

Create a pdfViewerAdapter.ts file that implements the collaboration provider contract, then create a CollaborationClient with the adapter and join the room after the PDF document has been loaded. See the platform-specific pages for the adapter and initialization examples:

Server packages

Choose one of the following Collaboration Server implementations:

Server Package Transport
Node.js ej2-collaborator-server WebSocket
ASP.NET Core Syncfusion.Collaborator.Server.AspNet.Core SignalR

The server implementation requires Redis. Configure the Redis connection and register the PDF Viewer server adapter before starting the server. Both servers expose the same service on the same port, so only the connectionType option differs on the client side. Use websocket for the Node.js server and signalr for the ASP.NET Core server.

Collaboration flow

  1. The adapter posts to ImportFile with the room name, PDF file name, and user name.
  2. The server returns the current version and pending PDF Viewer action snapshots.
  3. The client joins the room with CollaborationClient.joinRoomAsync.
  4. The PDF Viewer documentChanged event sends annotation, form field, form field action, or page organizer operations to UpdateAction.
  5. The server stores the operation and broadcasts the clean action request to the other users in the room.
  6. The adapter applies remote actions through the PDF Viewer collaborative editing handler.
  7. GetPDFDocument returns the current PDF content for the room, including the finalized document when it is available.

The Node.js sample uses the following routes under /api/CollaborativeEditing:

Route Purpose
POST /ImportFile Loads the room state and returns pending operations.
POST /UpdateAction Validates, stores, and broadcasts a PDF Viewer operation.
GET /GetPDFDocument Retrieves the PDF content for a room as Base64.
